1T All-electric truck carrying forklift
The main products include concrete pumps, from the ingredient concrete mixer truck, mortar spraying machine and forklift.
- Commodity name： 1T All-electric truck carrying forklift
- Product Description
-
Technical parameters
Technical paramete Feature Model MG10-11 MG10-13 MG10-15 Operation type Electric Load capacity kg 1000 Load center mm 400 Dimension Lifting height mm 1100 1300 1500 Mast lower height mm 1430 1630 1830 Mast extend height mm 2680 2880 3080 Overalllength mm 1660 Overall width of frame mm 910 Wheel base mm 995 Fork length mm 1220 Overall fork width mm 630 Fork inside width mm 240 MiniTurning radius mm 1300 Fork lowered height mm 90 Wheels Wheels type PU Front wheel mm 80*50 Size of drive wheels mm 210*75 Number of wheels pcs 5 Performance Lift speed (laden/unladen) mm/s 135/140 lowering speed(laden/unladen) mm/s 145/140 Gradeability % 3.0/5.0 Electrical configuration Hoist motor type DC Rated output kw 1.2 Battery voltage/capacity V/AH 24V48AH Weight Weight kg 390 400 410 Product detail
Produtc Video
Qualification Certificate
Workshop
Factory
